Specifications

Part Number 681-230
Catalog Page(s) D52,D53
System of Measurement Metric
ROHS Compliant [yes]
Certificate of Conformance Available [yes]
Vendor Series A-M™ Series
Washer Type Curved Non-Serrated
Material Spring Steel
Finish Plain
Compatible Hole Size 8 mm
Inside Diameter 8.2 mm
Outside Diameter 16 mm
Thickness 0.4 mm
Overall Height 0.90 mm
Height 0.0515"
Standard DIN 2093
