Part Number: 202-193

Spring Nut "U" Type for #8A or B SMS, Panel Range .025-.040" Spring Steel Heat Treated Two Coats Water Base Zinc Coating (Geomet) Color:Silver

Availability:
To view pricing and availability please either log in with a registered email address or register a free account.

Specifications

Part Number 202-193
System of Measurement Imperial
Speed Nut Type U-Type
Thread Size #8 - 15, #8 - 18
Nut Material Spring Steel
Nut Finish Zinc
Nut Coating Geomet
Overall Width 0.500"
Overall Length 0.520"
Hole Diameter Min 0.218"
Centre of Hole to Open Panel Edge 0.190"
Centre of Hole to Round Panel Edge 0.187"
Compatible Material Thickness 0.025"-0.040"
Brand Tinnerman®
Manufacturer's Part Number D08108-8-3255
