Part Number: 097-403

Flush Pull Latch, Non-Locking, 1.52"; 38.5 mm Case Length x 61 (Diameter) mm; 2.41 (Diameter) in Case Width x 12.5 mm; 0.49" Case THK, 0.98"-1.02"; 25 mm-26 mm Grip, 0.275"-0.475"; 7.000 mm-12.000 mm Panel THK, Plastic, Polycarbonate, Black, UL94-HB

Availability:
To view pricing and availability please either log in with a registered email address or register a free account.

Specifications

Part Number 097-403
Catalog Page(s) L110
Latch Type Flush Pull Latch
Material Plastic, Polycarbonate
Finish Black
Colour Black
Brand Southco®
Handle Type Flush
Lock Type Non-Locking
Case Length 1.52";38.5 mm
Case Width 61 (Diameter) mm;2.41 (Diameter) in
Case Thickness 12.5 mm; 0.49"
Handle Length 36 mm
Bolt Height 14 mm; 0.55"
Compatible Panel Thickness 0.275"-0.475";7.000 mm-12.000 mm
Grip 0.98"-1.02";25 mm-26 mm
Number of Mounting Holes 2
Centre-to-Centre Distance Between Mounting Holes (Length) 19 ±.0.15 mm; .750±.005 inch
Standards Met UL94-HB
