Disc Spring DIN 2093 AM-1506150 150mm OD x 61mm ID x 5.0mm TH Spring Steel Heat Treated Plain DIN 2093 150X61X5.0

Part Number: 681-384

Disc Spring DIN 2093 AM-1506150 150mm OD x 61mm ID x 5.0mm TH Spring Steel Heat Treated Plain DIN 2093 150X61X5.0

Availability:
To view pricing and availability please either log in with a registered email address or register a free account.

Specifications

Part Number 681-384
Catalog Page(s) D60,D61
System of Measurement Metric
Vendor Series A-M™ Series
Washer Type Curved Non-Serrated
Material Spring Steel
Finish Plain
Compatible Hole Size 60 mm
Inside Diameter 2.4000";+0.012";60.960 mm;+0.305 mm
Outside Diameter 150.114 mm;-0.406 mm;5.910";-0.016"
Thickness 0.197";0.005";4.994 mm;0.127 mm
Overall Height 0.406";+0.012";-0.012";10.300 mm;+0.30 mm;-0.30 mm
Standard SAE 6150
